Kohler 14 kW – Full House

Model 14RCAL-200 Manufacturer

Popular generators for backup power, with an automatic transfer switch included. When you lose power during an outage or storm, a hard-working 14 kW KOHLER® generator keeps your appliances working, the heat or AC running and your security system on.

Description

* Reliable.

Every KOHLER® generator is equipped with a heavy-duty, commercial-grade engine that stands up to extreme weather.

* Powerful.

In just 10 seconds, your KOHLER generator automatically restores power to a 5-ton (60,000 BTU) air conditioner, major appliances and electronics.*

* Premium warranty.

We’ve got you covered with 5-year, 2,000-hour protection, and a corrosion-proof enclosure that’s built to last.

* Award winner.

KOHLER generators have received several awards, including the Most Valuable Product (MVP) Award 2010 by Building Products magazine.

* THE POWER YOU NEED

PowerBoost™ technology provides power to start large loads such as central air conditioners without dropping power to other appliances

Extraordinary peak motor-starting capacity: 14RCA at 33kVA at 240V and 20RCA at 41kVA at 240V

Premium power quality delivers exceptional digital voltage and frequency regulation along with low levels of harmonic distortion to protect sophisticated electronics

Powered by reliable KOHLER Command PRO® engine, designed and tested for tough commercial applications; with hydraulic valve lifters to eliminate need for lengthy break-in periods and expensive valve adjustments; operation speed is 3600 rpm (the standard for air-cooled generators)

Compatible with OnCue® Plus and OnCue® Plus Wireless Generator Management Systems, and Programmable Interface Module (PIM)

Also compatible with Load Control Module (LCM) or Load Shed kit with single-phase generators only

* THE CONVENIENCES YOU EXPECT

RDC2 controller designed for today’s sophisticated electronics manages both the generator set and Model RXT transfer switch functions

Quiet, neighborhood-friendly operation with sound levels similar to a typical central air conditioner

Stylish corrosion-proof enclosure impact tested to -30 degrees F

Runs on either natural gas or liquid propane (LPG) with simple switching between natural gas and LPG in the field

Streamlined installation, simple terminal block for easy field connections. Kohler also offers concrete mounting pads to lower installation costs and time.

Get a Quote

Specifications

Model 14RCA
PHASE Single Phase or Three Phase
FUEL TYPE LPG/Natural Gas
OFF GRID / UTILITY BACKUP Utility Backup
ENCLOSURE MATERIAL Aluminum
PEAK MOTOR STARTING KVA @240 V 33 kVa
VOLTAGE @ 60 HZ 120/240/277/480
DISPLACEMENT  725 cm³ (44 cu. in.)
HORSEPOWER NG 20.5 HP, LP 23.6 HP
BUILT IN MOUNTING PAD Yes
SOUND OUTPUT DURING WEEKLY EXERCISE 63 dB(A)
SOUND OUTPUT DURING FULL-SPEED OPERATION 67 dB(A)
WARRANTY Premium five-year limited warranty
DIMENSIONS 1193 mm x 666 mm x 817 mm (47 in. x 26.2 in. x 32.2 in.)
WEIGHT 490/500 lbs. (222/227 kg)
COUNTRY OF ORIGIN US
CERTIFICATIONS/LISTINGS EPA|CSA|UL 2200|cUL
AUTOMATIC TRANSFER SWITCH INCLUDED Yes
REMORE MONITORING AVAILABLE Included
FUEL CONSUMPTION ON LP AT 50% LOAD? 60 cfh
FUEL CONSUMPTION ON NG AT 50% LOAD? 124 cfh
ALTERNATOR NOTE All information shown is 1 Phase 60 Hz generator with the largest alternator option available
ALTERNATOR TPYE 2-Pole, Rotating Field
CONTROLLER RDC2 Controller
CYLINDER ARRANGEMENT V-2
ENGINE MANUFACTURER/DESCRIPTION KOHLER
ENGINE MODEL CH1000
FREQUENCY 60 Hz
DIGITAL VOLTAGE REGULATION ±1.0%
NAME 14RCA with OnCue Plus
OFF GRID WARRANTY N/A
